Purpose of unit
The bench-scale laboratory unit for the study of gas chemical processes and the implementation of GTL technologies (hereinafter referred to as the Unit) is intended for testing the catalytic properties of industrial heterogeneous catalysts of gas-liquid conversion technology in the Fischer- Tropsch process.
Unit specifications
The unit is a laboratory five-reactor complex with partially automated control for conducting experimental research and is intended for operation in a dry heated room with forced ventilation. Electrical safety unit meet the requirements of class 1 type N according to GOST 12.2.025-76
|
Name |
Parameter value |
|
Operaing pressure, MPa Nominal volume of reactors (each) P 1 and P2, l Nominal volume of reactors (each) Р3, Р4 and Р5, l Maximum/working capacity of pumps H 1 and H2, ml/h Nominal volume of each container V 1 (raw materials) and V 2 (water), l Nominal volume of each separator SHP 1 and SHP2, l Nominal container volume V 3, l Heated lines for series connection of reactors, pcs. Operating temperature of oven No. 1 and No. 2, ° C Operating temperature of oven No. 3, No. 4 and No. 5, ° C Number of temperature-controlled zones in each oven No. 1 and No. 2, pcs. Power of oven (each) No. 1 and No. 2, kW Power of oven (each) No. 3, No. 4 and No. 5, kW Power of each raw material heater MH 1 and MH2, kW Evaporator-superheater power, kW Cryostat VT-12 power, kW Power supply of the unit Total electrical power consumption of unit, kW |
2,5 8 0,7 300/40 4 2 0,5 2 600 200 3 4 0,45 0,4 2,7 2,5 380V, 50 Hz ≤ 20 kW |
