Application
Unit is designed for processes simulation of obtaining petroleum pitch.
Operating conditions:
· ambient temperature from +10 to +35 °C ;
· relative air humidity no more than 80% at a temperature of 25 °C ;
Technical characteristics
|
Parameter |
Value |
|
Operating pressure range, MPa |
0 – 1,4 |
|
Operating temperature range of the reactor thermostat, °C |
50 - 450 |
|
Temperature setting accuracy, °C |
1 |
|
Maintaining temperature relative error, °C |
±0.5 |
|
Reactor material |
stainless steel |
|
Power consumption, kW |
less than 13 |
|
Power supply, single-phase network |
380V 50Hz |
|
Overall dimensions ( HxWxD ) |
1945x1185x745 |
|
Reactor volume, l |
14 |
|
Weight, kg |
165 |
|
Mode |
continuous |
Unit flow diagram
