GC-MS system Crystallux-4000M with MSD "MAESTRO-αMC"

Photo: GC-MS SYSTEM »

Special features

Convenient design

  • presence of the observation window and the indicator panel
  • modular design
  • lateral vacuum chamber design simplifies system maintenance

Reliable structure

  • Double filament reduces service frequency
  • The special design of the surface repulsion electrode and lenses greatly improves the focusing of ions
  • The presence of pre-quadrupoles allows to reduce the pollution of the main quadrupole
  • Molybdenum alloy quadrupole
  • Compact amplifier with a combined conversion technology effectively reduces noise and improves the signal-to-noise ratio

Flexible system

  • In accordance with your needs and budget, 2 specifications of a turbomolecular pump are available: standard and increased productivity
  • Integrated wireless module, Ethernet port, serial port and USB port provide extensive switching capabilities

User friendly

  • The software is intuitive and easy to use even for users without special training
  • With the remote access feature, our experts will help you manage the tool and analyze data

Features

Name of characteristics Value
Type of ionization EI
Transferline Capillary interface, independent temperature control, 50-300 °C
Filament Dual, maximum current 300 µA
Ionization energy 10-100 eV, regulated
Ion source temperature Ion source temperature 350 °C, adjustable
Auxiliary pump Mechanical pump, geometric pumping speed 165 l / min
Turbomolecular pump Turbomolecular pump, pumping speed 71l / s, 260 l / s (optional)
Linear range 107
Mass range 1,5-1200 amu
Mass accuracy ± 0,1 amu
Resolution (R) z 272 10 fg OFN with selective ion scanning - ≥150: 1 RMS with m / z 272
M/z stability ± 0,1 amu/48h
Maximum scan speed 20000 amu/s
