Application
The Pyrolyzer is designed to simulate the process of pyrolysis and obtain synthesis gas
|
Specifications |
Value |
|
Operating temperature range of the reactor,°С |
20÷1100 |
|
Inner diameter of reactor, mm |
10÷60 |
|
Reactor length, mm |
1350 |
|
Thermocouple pocket |
included |
|
Isothermal zone length, mm |
700 |
|
Oven type |
Swing |
|
Number of independent temperature-controlled zones |
1 |
|
Temperature setting resolution, °С |
1 |
|
Liquid pump flow range, ml/min |
0÷1000 |
|
«Pipe in pipe» refrigerator |
included |
|
2 separators |
included |
|
Resin collection container |
included |
|
Power supply, V(Hz) |
220(50) |
|
Power consumption, kW |
3,3 |
|
Overall dimensions, mm |
1400х400х1250 |
|
Weight, kg |
100 |
