Application:
Micropilot unit is designed for hydrotreating oil fractions
Specifications:
- Reactor made of stainless steel with an operating temperature of up to 600 °C and a pressure of up to 30 MPa, with a coaxial pocket for a control thermocouple and a movable grid for the catalyst fixed to it;
- 4-zone door oven with a range of operating temperatures from 50 to 600 °C;
- High-pressure separator SVD (30 MPa) heated to 80 °C with a level sensor and automatic overflow into the heated SND, a valve and a dephlegmator at the gas outlet;
- Automatic pressure maintenance system based on a heated mechanical pressure regulator “before itself” with a range from 0 to 25 MPa;
- Automatic compensation system for pressure drop during overflow from SVD to SND;
- Electronic hydrogen flow regulator;
Pmax = 26 MPa, Q = from 10 to 800 ml/min.;
- Liquid dosing pump with heated head Q = 0.1-50 ml/min., Pmr ≥ 30 Mpa;
- 2-liters raw material container installed on the scales, heated to 80°C, with nitrogen pressure;
- Container with a solvent for flushing the pump with a volume of 2 liters and nitrogen pressure;
- Heated oil supply and discharge lines to the pump;
- Pressure sensors and safety valves at the inlet and outlet of the reactor;
- Automatic security system;
- Check valves on gas lines;
- Ramp pressure reducers for H2 and N2 (300/260);
- Control unit with a personal computer for entering and displaying modes; experiment and storing information about the dynamics of the process and its results.
Options:
- 30 MPa pressure hydrogen station with hydrogen generator or cylinder with up to 15 MPa pressure;
- gas meter;
- gas chromatograph with hydrogen generator and compressor.
