НТ2800T
Autosampler «НТ2800T»
Autosampler “HT2800T” (manufactured by “HTA s.r.l.” Italy-Brescia) is a single device combining possibilities of liquid autosampler and headspace sampler. Switch from one mode to another takes about 5 minutes and consists of the change of dosing syringe and of the tray with samples..
«RPC «Meta-chrom» is authorized distributor distributor for products of «HTA s.r.l.» company in Russia».
Photo: Autosampler «НТ280T» with chromatograph «Crystallux-4000М»
Technical characteristics
- Number of analyzed liquid samples is up to 121, equilibrium vapor up to 42.
- Data exchange with PC – by standard interface LAN.
- Data exchange with chromatograph – by specific interface (TTL-logic).
- Vial volume for analyzed liquid sample is 2 ml, for equilibrium vapor 20 or 10 ml.
- Possibility to insert the sample consequently into two injectors.
- The ability set any sequence of injection of samplers from the vial tray.
- Other characteristics of the sampler are identical to the characteristics of HT2000, HT3000A
- Possibility of manual setting of autosampler for particular chromatograph by step-by-step programming from control panel and recording this setting parameters in memory.
- Possibility of manual insertion of the sample without dismantling of the sampler from the chromatograph.
- Possibility to work with any gas chromatograph, including “Crystall”, “Crystallux” series, etc.
- Electric power from single-phase network AC power with voltage from 198 to 242 V, frequency (50±1) Hz, power consumption - no more than 160 VA.
- Overall dimensions (widthxdepthxheight) – no more than 420x400x620 mm.
- Mass – no more than 11,5 kg.
During work with chromatograph of “Crystallux” series sampler control is realized directly from chromatograph software without running additional programs.
