НТ3000А
Liquid sample injector «НТ3000А»

Liquid autosampler “HT3000A” (manufactured by “HTA, Italy) is designed for automatic injection of liquid samples. RPC Meta-chrom is the official distributor of HTA s.r.l (Italy-Brescia), which produces autosamplers. You can order an autosampler from us at an affordable price with delivery to the specified address.

RPC “Meta-chrom” is authorized distributor for products of “HTA s.r.l.” company in Russia.

Photo: Liquid sample injector «НТ3000А»

Technical characteristics

  • Number of analyzed samples - from 1 to 121 (tray for 121 samples). There is “HT3200A” modification for 209 samples with two trays.
  • Data exchange with PC - by standard interface LAN.
  • Data exchange with chromatograph - by specific interface (TTL-logic).
  • Vial volume for analyzes samples - 2,0 ml.
  • Sampling and injection speed - from 1 to 100 mcl/s.
  • Standby time before and after injection - from 0 to 99 s.
  • Viscosity delay during injection - from 0 to 15 s.
  • Possibility to inject the sample in series into two evaporators.
  • Possibility of manual setting of the sampler for specific chromatograph by step-by-step programming from control panel, recording this setting parameters in memory.
  • Possibility of setting different modes of sample injection and syringe flush (like with sample so with 4 solvents up to 15 flushes during every sample injection or injection of group of samples).
  • Setting any order of sample injection from vials on the tray.
  • Volume of injected sample - from 0,02 to 99 mcl (syringes 0,5, 1, 5, 10, 25, 50 and 100 ml).
  • Extraction of air bubbles from the syringe - up to 15 pumpings.
  • Possibility of sample injection with inner standard and sandwich injection.
  • Possibility of manual injection of the sample without dismantling of the sampler from the chromatograph.
  • Possibility to work with any gas chromatograph, including “Crystall”, “Crystallux” series, etc.
  • Electric power from single-phase network AC power with voltage from 198 to 242 V, frequency (50±1) Hz, power consumption - no more than 160 VA.
  • Overall dimensions (width×depth×height) - no more than 280×320×570 mm.
  • Mass - no more than 8 kg.

During work with chromatograph of “Crystallux” series sampler control is realized directly from chromatograph software without running additional programs.
