Photo: Device «Vodoley»
Purification of water in the device is done by letting the water pass through composition of deionized resin and sorbents. Resins and sorbents are located in filter elements, placed into the removable cartridge. Distilled water that needs to be purified is poured into the feeding tank, filler neck of the tank is located on the upper surface of the device and is hermetically closed by screw cap.
Excess pressure is created in the filling tank during the work of device with the help of microprocessor, under its influence purified water is pushed through filter elements and goes to the output of device.
Electric power Hydrogen generator power is from single-phase network AC power with voltage from 187 to 242 V, frequency (50±1) Hz, work mode – continuous.
Technical characteristics
| Name of characteristics | Value |
| Specific conductivity of obtained water, no more than, mcSхcm | 0,20 |
| Productivity, no less than, l/hour | 6 |
| Operating time of removable cartridge (overall volume of purified water), no less thyan, l | 700 |
| Volume of distilled water poured into the tank, l. | 1 |
| Power input, no more than, VА | 20 |
| Overall dimensions (width×depth×height), mm | 180×450×380 |
| Mass of the filled device, no more than, kg | 8 |
